Front IP65 Panel PC

www.alvasta-tech.com / Industrial / Winmate / Industrial Panel PC and HMI / Industrial Panel PCs (Resistive Touch) / Front IP65 Panel PC /

Front IP65 Panel Pc

Winmate's IP65 industrial panel pc features a waterproof and dustproof front panel designed for industrial and commercial applications.

R05FA3S-IPD1

5.7" NXP i.MX6 Front IP65
touchscreen panel

KEY FEATURES

  • 5.7" 640 x 480 TFT LCD with resistive touch screen,IP65 touchscreen panel
  • NXP i.MX6 Dual Core 1 GHz (Optional Quad Core)
  • 1 x USB 2.0, 1 x RS232/422/485, 1 x Micro SD Slot
  • Onboard LPDDR3 1 GB (Optional 2 GB)
  • Onboard 16 GB eMMC Flash
  • 1 x USB 2.0, 1 x RS-232/422/485,
    1 x Micro SD Slot, 1 x Mini USB, 1 x Micro HDMI (Optional)
  • PoE function (Optional)
  • Fanless and ultra-low power consumption

R06IE3S-IPA1

6.5" Intel® Celeron® N6210 Front IP65 Panel PC

KEY FEATURES

  • 6.5” TFT SVGA LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0

R06IB3S-IPA

16.5" Intel® Celeron® N2930
Front IP65 Panel PC

KEY FEATURES

  • 6.5" TFT SVGA LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • 1 x SO-DIMM, max. 8 GB DDR3L 1600
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI
  • 2 x Gigabit Ethernet
  • 1 x SATA, 1 x USB 2.0,1 x USB 3.0, 1 x HDMI, 2 x COM, 1 x Mini PCIe slot

W07IE3S-IPT1

7" Intel® Celeron® N6210 Front
IP65 Panel PC

KEY FEATURES

  • 7” TFT SVGA LCD
  • Intel® Celeron® Elkhart Lake N6210
    Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM,
    2 x USB 3.2 Gen 1, 4 x USB 2.0

W07IB3S-IPT

17" Intel® Celeron® N2930 Front IP65 Panel PC

KEY FEATURES

  • 7" TFT SVGA LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8 GB
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI
  • 2 x Gigabit Ethernet
  • 1 x SATA, 1 x USB 2.0,1 x USB 3.0, 1x HDMI, 2 x COM, 1x Mini PCIe slot

W07FA3S-IPT

17" NXP i.MX6 Front
IP65 Panel PC

KEY FEATURES

  • 7" 1024 x 600 TFT LCD with resistive touch screen
  • NXP i.MX6 Dual Core 1 GHz (Optional Quad Core)
  • Front IP65 protection
  • Onboard LPDDR3 1 GB (Optional 2 GB)
  • Onboard 16 GB eMMC Flash
  • 1 x USB 2.0, 1 x RS-232/422/485,
    1 x Micro SD Slot, 1 x Mini USB, 1 x Micro HDMI (Optional)
  • PoE function (Optional)
  • Fanless and ultra-low power consumption

R08IE3S-IPT1WT

8.4" Intel® Celeron® N6210 Front
IP65 Wide Temperature Panel PC

KEY FEATURES

  • 8.4” TFT SVGA LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM,
    2 x USB 3.2 Gen 1, 4 x USB 2.0
  • Front IP65

R08IE3S-IPU1

8.4" Intel® Celeron®
N6210 Front IP65 Panel PC

KEY FEATURES

  • 8.4” TFT SVGA LCD Front IP65 Panel PC
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0

R08IB3S-IPU

18.4" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 8.4" TFT SVGA LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8 GB
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI (Optional)
  • 2 x Gigabit Ethernet
  • 1 x SATA, 1 x USB 2.0,1 x USB 3.0, 1 x HDMI (Optional), 2 x COM, 1x Mini PCIe slot

R08IB3S-IPT1WT

8.4" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 8.4" TFT SVGA LCD
  • Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Processor
  • SODIMM DDR3L 1600/1333, max. 8 GB
  • 2 x RS232, 1 x RS232/422/485, 1 x USB 3.0, 1 x USB 2.0, 2 x RJ45, 1 x HDMI, 1 x SATA II,
    2 x Mini PCIe
  • Front IP65 protection against water and dust
  • -20~60°C operating temperature

W10IE3S-IPH2

10.1" Intel® Celeron® N6210 Front IP65 Panel PC

KEY FEATURES

  • 10.1” TFT LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0

W10IB3S-IPH2

10.1" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 10.1" TFT LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8 GB
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI (Optional)
  • 2 x Gigabit Ethernet
  • 1 x SATA, 1 x USB 2.0,1 x USB 3.0, 1 x HDMI (Optional), 2 x COM, 1 x Mini PCIe slot

R10IE3S-IPA1WT

10.4" Intel® Celeron® N6210 Front
IP65 Wide Temperature Panel PC

KEY FEATURES

  • 10.4” TFT LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0
  • Front IP65

R10IE3S-IPT2

10.4" Intel® Celeron®
N6210 Front IP65 Panel PC

KEY FEATURES

  • 10.4” TFT XGA LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0

R10IP7T-IPA1WT

10.4" Intel® Pentium® N4200 Front
IP65 Panel PC

KEY FEATURES

  • Intel® Pentium® N4200 Apollo Lake Processor 1.10 GHz
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.0 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2160 @ 60 Hz
  • HDMI Support 3840 x 2160 @ 30 Hz

R10IB3S-IPT2

10.4" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 10.4" TFT XGA LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8GB
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI (Optional)
  • 2 x Gigabit Ethernet

R10IB3S-IPA1WT

10.4" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 10.4" TFT SVGA LCD
  • Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Processor
  • SODIMM DDR3L 1600/1333, max. 8 GB
  • Front IP65 protection against water and dust
  • -20~60°C operating temperature
  • Integrated VGA, Dual­channel 24­bit LVDS, HDMI (Optional)

R12IE3S-IPM2WT

12.1" Wide Temperature Panel PC with Intel® Celeron® N6210, Front IP65

KEY FEATURES

  • 12.1” TFT LCD Wide Temperature Panel PC
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0
  • Front IP65

R12IE3S-IPM2

12.1" Intel® Celeron® N6210 Front
IP65 Panel PC

KEY FEATURES

  • 12.1” TFT LCD
  • Intel® Celeron® Elkhart Lake N6210 Processor
  • 1 x SO-DIMM, max. 16GB DDR4
  • 2 x Gigabit Ethernet
  • Supports 2 x SATA III, 4 x COM, 2 x USB 3.2 Gen 1, 4 x USB 2.0

R12IP7T-IPM2WT

12.1” Intel® Pentium® N4200 Front
IP65 Panel PC

KEY FEATURES

  • Intel® Pentium® N4200 Apollo Lake Processor 1.10 GHz
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.0 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2160 @ 60 Hz
  • HDMI Support 3840 x 2160 @ 30 Hz

R12IB3S-IPM2

12.1" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 12.1" TFT XGA LCD
  • Intel® Celeron® N2930 Quad Core 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8GB
  • Integrated VGA, Dual-channel 24-bit LVDS, HDMI (Optional)
  • 2 x Gigabit Ethernet

R12IB3S-IPM2WT

12.1” Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 12.1" TFT XGA LCD
  • Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Processor
  • SODIMM DDR3L 1600/1333, max. 8GB
  • 2 x RS232, 1 x RS232/422/485, 1 x USB 3.0, 1 x USB 2.0, 2 x RJ45, 2 x PS/2, 1 x VGA, 1 x SATA II, 2 x Mini PCIe, 1 x eDP
  • Front IP65

R15IT7T-IPA3WT

15" Intel® Core™ i5 (Tiger Lake) Front
IP65 Panel PC

KEY FEATURES

  • Intel® Core™ Tiger Lake UP3 i5-1135G7?Without vPro?/ Intel® Core™ Tiger Lake UP3 i5-1145G7E?With vPro?
  • 1024 x 768 Resolution
  • Multi display supports DP / HDMI / LVDS / eDP panel interface
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.2 Gen. 1 Ports
  • 12V Single Voltage Power Input
  • Front IP65 water and dust proof

R15IT7T-IPC3

15" Intel® Core™ i5 (Tiger Lake) Front
IP65 Panel PC

KEY FEATURES

  • Intel® Core™ Tiger Lake UP3 i5-1135G7?Without vPro?/ Intel® Core™ Tiger Lake UP3 i5-1145G7E?With vPro?
  • 1024 x 768 Resolution
  • Multi display supports DP / HDMI / LVDS / eDP panel interface
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.2 Gen. 1 Ports
  • 12V Single Voltage Power Input
  • Front IP65 water and dust proof

R15IP7T-IPC3

15" Intel® Pentium® N4200 Front
IP65 Panel PC

KEY FEATURES

  • Intel® Pentium® N4200 Apollo Lake Processor 1.10 GHz
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.0 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2160 @ 60 Hz
  • HDMI Support 3840 x 2160 @ 30 Hz

R15IP7T-IPA3WT

15” Intel® Pentium® N4200 Front
IP65 Panel PC

KEY FEATURES

  • Intel® Pentium® N4200 Apollo Lake Processor 1.10 GHz
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.0 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2160 @ 60 Hz
  • HDMI Support 3840 x 2160 @ 30 Hz

R15IF7T-IPC3

15" Front IP65 Panel PC with Intel® Core™ i3/i5/i7 (Coffee Lake Refresh)

KEY FEATURES

  • 15” 1024 x 768 Resolution Front IP65 Panel PC
  • Intel® 9th Gen. Core™ i3/i5/i7 Processor (Coffee Lake Refresh)
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.2 Gen. 1 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2304 @ 60 Hz
  • HDMI Support 4096 x 2304 @ 24 Hz

R15FA3S-IPC3

15" NXP i.MX6 Front
IP65 Panel PC

KEY FEATURES

  • 1024 x 768 TFT LCD with resistive touch screen
  • NXP i.MX6 Dual Core 1 GHz (Optional Quad Core)
  • Front IP65 protection
  • Onboard LPDDR3 1 GB (Optional 2 GB)
  • Onboard 16 GB eMMC Flash
  • 1 x USB 2.0, 1 x RS-232/422/485, 1 x Micro SD Slot, 1 x Mini USB, 1 x Micro HDMI (Optional)
  • PoE function (Optional)
  • Fanless and ultra-low power consumption

R15IK7T-IPC3

15" Intel® Core™ i3/i5/i7 (Kaby Lake) Front IP65 Panel PC

KEY FEATURES

  • 15" 1024 x 768 Resolution
  • 7th Gen. Intel® Core™ i3/i5/i7 processor Kaby Lake
  • Flexible storage devices, one 2.5-inch HDD and one SSD socket
  • Multiple I/Os, 2 x Serial Ports, 4 x USB 3.0 Ports
  • 12 V DC Power input
  • DP Support 4096 x 2304 @ 60 Hz
  • HDMI Support 4096 x 2304 @ 24 Hz

R15IB7T-IPC3

15" Intel® Celeron® N2930 Front
IP65 Panel PC

KEY FEATURES

  • 15" TFT XGA LCD
  • Intel® Celeron® Bay Trial-M N2930 1.83 GHz Processor
  • SO-DIMM DDR3L 1600, max. 8 GB
  • Integrated VGA, 24 bit Dual-channel LVDS, DVI
  • Integrated Dual Broadcom I210AT GbE Controller
  • 1 x SATA II, 3 x COM, 3 x USB 2.0, 1 x USB 3.0, 2 x Mini PCIe slot
