OVERVIEw
The marine Panel PCs are designed for maritime applications and IoT integration to assist with vessel navigation, monitoring & surveillance, and ship automation systems. Winmate's Marine Series are all tested for Marine grade certificates to meet international maritime regulations. Winmate ECDIS Marine Panel PCs are built and tested according to DNV Standard Certification 2.4, IEC60945, and IACS-E10 for naval applications. Color calibrated for ECDIS compliance, dimming brightness, projective capacitive multi-touch screen, capacitive touch keys, and wide voltage range power input 9-36 V DC.
To meet the marine industry's regulatory requirements, Winmate offers certified solutions for shipping navigation, monitoring and surveillance, and ship automation systems. Winmate understands the needs of the marine industry and provides solutions to industrial challenges:
Extreme environments
Naval workstations and panel PCs face extreme environments such as temperature changes, strong vibration, and water drops.
Accurate chart depiction
An accurate chart displaying is crucial in maritime applications.
Data collection
The need to collect data from barcodes, RFID tags, on-site photos, and videos from different sources.
Day, night, and dusk
The onboard monitor and screen must provide viewability in day, night, and dusk conditions.
For more than 25 years, Winmate Inc.- has provided robust and reliable solutions to our customers and partners in the marine sector. We are the preferred supplier of Marine Computers and Marine Displays for leading OEMs in the marine sector, especially for ECDIS, Radar, Automation, and communication applications. Robust and elegant designs with years of experience producing marine electronics solutions have made Winmate Inc. the leader in this field.
| | |
R10L210-MRM210.4" Marine DisplayKEY FEATURES- 10.4" 800 x 600 resolution Marine Display
- Resistive touch screen (Optional protection glass w/o touch function)
- IP66 aluminum housing with powder coating design (IP54 rear)
- 24 V DC power supply with terminal block (Default, isolation resistance)
- Picture-in-picture (PIP) function and multi-video inputs
- Ease-of-use front panel OSD control
- Enhanced shock and vibration resistance
- Certified DNVGL-CG-0339, IEC60945 4th, IACS E10
- Dimming knob to control backlight brightness from nearly 0% to 100%
Learn more... | R12L600-MRM2HB12.1" High Brightness Marine DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- High brightness TFT-LCD Panel enhances the best visibilty(Optional)
- IP66 aluminum housing with powder coating design (IP54 rear)
- 9 to 36V DC to DC power input acceptable (AC power for option)
- High quality touchscreen / AR protection glass for option
- PIP(picture in picture) function and multi-video inputs
- Ease of use front panel OSD control, High Brightness Marine Display
- Enhanced shock and vibration resistance
Learn more... | R12L600-MRM212.1" Marine DisplayKEY FEATURES- 12.1" 1024 x 768 resolution
- Resistive touch screen (Optional protection glass w/o touch function)
- IP66 aluminum housing with powder coating design (IP54 rear)
- 9 to 36 V DC power supply with terminal block (Default)
- Picture-in-picture (PIP) function and multi-video inputs
- Ease-of-use front panel OSD control
- Enhanced shock and vibration resistance
- Certified DNVGL-CG-0339, IEC60945 4th, IACS E10
- Dimming knob to control backlight brightness from nearly 0% to 100%
Learn more... |
| | |
R15L100-MRC3HB15" Marine High Brightness DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- High brightness TFT-LCD panel enhance the best visibility
- Panel (flush) mount with IP66 aluminum housing design (IP54 rear)
- 9 to 36V DC to DC power input acceptable (AC power for option)
- High quality touchscreen / AR protection glass for option
- PIP(picture in picture) function and multi-video inputs
- Ease of use front panel OSD control
- Enhanced shock and vibration resistance
Learn more... | R15L600-MRM215" Marine DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- Marine Display with High resolution 1024 x 768 panel
- IP66 aluminum housing with powder coating design (IP54 rear)
- 24V DC to DC power input acceptable (Isolation Resistance)
- High quality touchscreen / AR protection glass for option
- PIP(picture in picture) function and multi-video inputs
- Ease of use front panel OSD control
- Enhanced shock and vibration resistance
Learn more... | R17L500-MRM117" Marine Display with Dimming knob controlKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- IP66 aluminum housing with powder coating design (IP54 rear)
- 9 to 36V DC to DC power input acceptable
- High quality touchscreen / AR protection glass for option
- Ease of use front panel OSD control Marine Display
- Enhanced shock and vibration resistance
Learn more... |
| | |
R19L300-MRA119" Marine DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- Transflective film technology enhance visibility
- IP66 aluminum housing with powder coating design (IP54 rear)
- 24 V DC to DC power input acceptable (Isolation Resistance)
- High quality touch screen / AR protection glass for option
- PIP(picture in picture) function and multi-video inputs
- Ease of use front panel OSD control, Marine Display
- Enhanced shock and vibration resistance
Learn more... | W24L100-MRL1FP23.8” 4K UHD Marine DisplayKEY FEATURES- 23.8” 4K UHD with projective capacitive multi-touch screen
- Multi Video Output ,VGA+DVI+HDMI+DP
- 24V DC power input
- fanless cooling system
Learn more... | W24L100-MRA124" Marine DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- IP66 aluminum housing with powder coating design (IP54 rear)
- 24V DC Isolated Power Module
- High quality touchscreen / AR protection glass for option
- Ease of use front panel OSD control Marine Display
- Enhanced shock and vibration resistance
Learn more... |
| | |
W24L100-MRA1HB24" Marine High Brightness DisplayKEY FEATURES- Dimming knob control backlight brightness from nearly 0% to 100%
- High Brightness technology enhance visibility
- IP66 aluminum housing with powder coating design (IP54 rear)
- 24V DC Isolated Power Module, Marine High Brightness Display
- High quality touchscreen / AR protection glass for option
- Ease of use front panel OSD control
- Enhanced shock and vibration resistance
Learn more... | W32L100-MRA3FP 32" Marine DisplayKEY FEATURES- High image quality, 1920 x 1080 pixels resolution Marine Display
- 9~36 V DC to DC power input acceptable (Isolation Resistance)
- High quality touchscreen / AR protection glass for option
- Ease of use front panel OSD control Marine Display
- Enhanced shock and vibration resistance
- Panel Mount
Learn more... | M320TF-MR 32" 4K Chassis Marine DisplayKEY FEATURES- 32” 4K Chassis Marine Display (3840 x 2160) native resolution
- Capacitive touch keys for quick function access and display control
- Thin and Compact Design with impact resistant screen
- AR glass, PCAP touch optional Display
- Fanless cooling design
- VESA Mount
Learn more... |
