G-WIN VM Series Panel PC

www.alvasta-tech.com / Industrial / Winmate / Industrial Panel PC and HMI / G-WIN Series / G-WIN VM Series Panel PC /

G-WIN VM Series Panel PC

OVERVIEW

Winmate's G-WIN VM Series Panel PC consists of rugged and unusually well-sealed vehicles or stationary-mount and available in a wide variety of configurations. Rugged, reliable, and powerful computing for in-vehicle applications.


R08IB3S-VMU1 8.4" Intel® Celeron® N2930 G-WIN Vehicle Mount Panel PC FEATURES Intel® Celeron® Bay Trail N2930 1.83GHz Processor Fanless Design High Quality 8.4" Panel, 800 x 600 resolution Front IP65 Dust / water resistant Protection (Except I/O parts) Aluminum Housing with Anti-Corrosion Treatments Anti-Shock and Vibration Standard according to MIL-STD-810F/G 5 Wire Resistive Touchscreen / Anti-Reflection Protection Glass (Optional) WLAN with Antenna (Optional) 10 ~ 60V DC Isolation Wide Range Power Input. Optional Ignition on/off control function. Design to meet EN50155 Learn more...	R10IW3S-VMT2(HB) 10.4" Intel® Core™ i5 G-WIN Vehicle Mount Panel PC FEATURES 8th Generation (Whiskey Lake) Intel® Core™ i5-8265U 1.6GHz (turbo to 3.9GHz) High Quality 10.4" Panel, 1024 x 768 resolution Front IP65 Dust / Water Proof Enclosures (Except I/O parts) Aluminum Housing with Anti-Corrosion Treatments Anti-Shock and Vibration Standard according to MIL-STD-810 & IEC60068-2-27 5 Wire Resistive/ Anti-Reflective Protection Glass Optional GPS, WWAN/ WLAN (Either One). GPIO/ Canbus (Either One) Wide Range 9 to 36V DC Input with isolation Optional 6-60 V DC Input, and Optional for Ignition On/Off delay Compliance with EN50155 for EMC & Characteristic Learn more...	R10IB3S-VMT2(HB) 10.4" Intel® Celeron® N2930 G-WIN Vehicle Mount Panel PC FEATURES Intel® Celeron® Bay Trail N2930 1.83 GHz Processor Fanless Design High Quality 10.4" Panel, 1024 x 768 resolution Front IP65 Dust / Water Proof Enclosures (Except I/O parts) Aluminum Housing with Anti-Corrosion Treatments Anti-Shock and Vibration Standard according to MIL-STD-810 & IEC60068-2-27 WLAN with Antenna (Optional) 10 ~ 60V DC Isolation Wide Range Power Input. Optional Ignition on/off control function. Compliance with EN50155 Learn more...

R10IK3S-VMT2(HB) 10.4" Intel® Core™ i5 G-WIN Vehicle Mount Panel PC FEATURES 10.4" 1024 x 768 panel Intel® Core™ i5-7200U Kaby Lake Aluminum housing with anti-corrosion treatments Front IP65 (Except I/O parts) Anti-Shock & Vibration compliant with MIL-STD-810F/G & IEC60068-2-27 Learn more...	W12IB3S-VMM9(HB) 12.1" Intel® Celeron® N2930 G-WIN Vehicle Mount Panel PC FEATURES Intel® Celeron® Bay Trail N2930 1.83 GHz Processor Fanless Design 5 Wire resistive touch screen -10 ~ +55°C Wide Range Operating Temperature Anti-Corrosion housing with Fanless Design WLAN with Antenna (Optional) Anti-Shock & Vibration compliant with MIL-STD-810F/G 10 ~ 60V DC Isolation Wide Range Power Input. Optional Ignition on/off control function. Panel Mount for request Design to meet EN50155 Learn more...	R15IK3S-VMC3(HB) 15" Intel® Core™ i5 G-WIN Vehicle Mount Panel PC FEATURES 7 Generation (kaby Lake) Intel® Core™ i5-7200U 2.5GHz (turbo to 3.1GHz) Vehicle Mount Panel PC High Quality 15" Panel, 1024*768 resolution, 300 nits (Optional for 1000 nits) Front IP65 Dust/ Water proof design with VESA mount Aluminum Housing with Anti-Corrosion Treatments Built-in ambient Light sensor Wide Range 9 to 36V DC Input with isolation 0ptional 6-60V DC Input, and Optional for Ignition 0n/0ff delay 5 Wire Resistive Touch / Anti-Reflective Protection Glass (Optional) Optional GPS, WWAN/WLAN(Either one). GPIO/Canbus(Either one) Learn more...

R15IB3S-VMC3(HB) 15" Intel® Celeron® N2930 G-WIN Vehicle Mount Panel PC FEATURES Intel® Celeron® Bay Trail N2930 1.83GHz Processor Fanless Design High Quality 15" Panel, 1024*768 resolution, 300 nits (Optional for 1000 nits) Front IP65 Dust/ Water proof design with VESA mount Aluminum Housing with Anti-Corrosion Treatments Built-in ambient Light sensor Vehicle Mount Panel PC WLAN with Antenna (Optional) Optional 6-60V DC Input, and Optional for Ignition On/Off delay 5 Wire Resistive Touch / Anti-Reflective Protection Glass (Optional) 10 ~ 60V DC Isolation Wide Range Power Input. Optional Ignition on/off control function. Optional HB/Sunlight Readable up to 1000 nits Design to meet EN50155 Learn more...

G-WIN VM Series Panel PC

R08IB3S-VMU1

R10IW3S-VMT2(HB)

R10IB3S-VMT2(HB)

R10IK3S-VMT2(HB)

W12IB3S-VMM9(HB)

R15IK3S-VMC3(HB)

R15IB3S-VMC3(HB)
