DAC-CX10 provides a cost-effective solution for data transmission/storage or other application, suitable for business to connect switches to routers or servers within racks and across adjacent racks.
DAC-CX10 is designed for providing high-speed data link via copper wire and support both Gigabit and 10 Gigabit Ethernet data rate, compatible to SFP+ MSA to meet Fiber Channel industry standard requirements to ensure performance and reliability.
It is available in 2 models, DAC-CX10-1m (Length:1m) and DAC-CX10-3m (Length:3m).
Specification | |
| Connetor | SFP or SFP+ |
| Type | Copper Passive |
| Length | 1m / 3m |
| Link Speed | 1GbE & 10GbE Capable |
| Wire gauge | AWG 30 |
| Power Supply | 3.3V |
| Power Consumption | Max. 0.2 Watt |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity (non-condensing) | 0°C to 85°C |
| Certificate | RoHS   |
