Specification | |
| Operation Band | 2.4GHz and 5GHz |
| 2.4GHz Frequency Range | 2400 to 2500 MHz |
| 2.4GHz Gain | 7.5 dBi |
| 2.4GHz HPBW Horizontal | 70° |
| 2.4GHz HPBW Vertical | 60° |
| 5GHz Frequency Range | 5150 to 5875 MHz |
| 5GHz Gain | 10 dBi |
| 5GHz HPBW Horizontal | 60° |
| 5GHz HPBW Vertical | 30° |
| Voltage Standing Wave Ratio (VSWR) | < 2.0 |
| Polarization | Vertical, Linear |
| Power Handling | 2W |
| Impedance | 50 ? |
| Connector | RP SMA Plug |
| Dimension | 66mm (L) x 120mm (H) x 18mm (W) |
| Environment | Indoor |
