SATA Slim 3TG6-P

SATA Slim

128GB ~ 512GB

Features

SATA Slim solution for industrial field
High IOPS
iSMART disk health monitoring
End-to-End Data Path Protection
iData Guard for abnormal power failure
iPower Guard for protecting unstable start up and shut down
Supports wide temperature from -40°C to 85°C

BORN FOR SUPERIOR PERFORMANCE

Innodisk SATA Slim 3TG6-P is SATA III 6.0Gb/s solid state disk, which delivers excellent performance, especially in random data transfer rate, and which offers reliability making it the ideal solution for a variety of applications, including embedded system, industrial computing, and enterprise field. 3TG6-P SATA Slim not only performs unmatched performance, but also designed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability.

SPECIFICATIONS

Model Name	SATA Slim 3TG6-P
Flash Type	3D TLC
Interface	SATA III 6.0 Gb/s
Form Factor	MO-297
Capacity	128GB ~ 512GB
Sequential R / W (MB/sec, max.)	550 / 510
P/E Cycle	3,000
TBW (Max.)	1,154
Storage Temperature	-40°C ~ 85°C
Max. Power Consumption	3W
Max. Channels	4
External DRAM Buffer	Y
Feature	AES, TCG Opal 2.0, S.M.A.R.T.
Dimension (W x L x H/mm)	54.0 x 39.0 x 4.0
Vibration	20G@[7 ~ 2000Hz]
Shock	1500G@0.5ms
MTBF	>3 million hours
Warranty	3 Years

ORDER INFORMATION

Operating Temperature	Standard Grade (0°C ~ 70°C)	Industrial Grade (-40°C ~ 85°C)
128GB	DGSLM-A28M71EC1QF	DGSLM-A28M71EW1QF
256GB	DGSLM-B56M71EC1QF	DGSLM-B56M71EW1QF
512GB	DGSLM-C12M71EC1QF	DGSLM-C12M71EW1QF
