CPU | Intel® Tigerlake U Celeron/Core I3/I5/I7 CPU |
System Memory | 2*DDR4 SO-DIMM slot, support 3200MHz, max 64GB |
Expansion | 1*full size Mini PCIe?with PCIe X1+USB2.0 signal?support Wifi/BT module |
1*M.2 3052 B-Key, with SIM slot?PCIe X1+USB2.0?support 4G LTE, 5G NR module |
1*M.2 22080 M-Key , PCIex2 Gen4.0 signal, support high speed signal function card |
Graphics | Intel UHD Graphics or iRIS® X? Graphics , Supports Intel DL boost deep learning technology?DirectX12.1, OpenGL 4.6 and OpenCL 2.0 |
HDMI 2.0 max res 4096x2304@60Hz?DP 1.4 max res 7680x4320@60Hz |
Audio | Realtek ALC662 controller(Opt) |
LAN | 3*Intel I225V, 10M / 100M / 1000M / 2.5G self-adapt?support iAMT 13.0 |
Storage | 1*2.5”SATA bay?max support 6.0Gbps transport speed; 1*full size mSATA?support AHCI |
1*M.2 22080 M-Key NVME(PCIex2 Gen4.0? |
I/O Interface | 3*2.5G-LAN(RJ45, with anti-screw hole) ?1*HDMI+1*DP?1*Audio out ? 1*Mic dual 3.5mm phone jack |
2*USB3.2 (Type A gen 2.0?one of them with anti-screw hole) , max support 10.0Gbps transport speed |
2*USB2.0(Type A?one of them with anti-screw hole)?1*USB2.0(Type A) internal?1*USB2.0 internal pinheader |
2*RS232/422/485 (DB9 Male)?1*MIO (opt support internal expansion module? |
1*8-bit DIO (2*5Pin phoenix term?side)?1*SIM slot?slot? |
I-port | Support internal 1*USB2.0, or Mini-PCIe?M.2 and ect expansion module such as dual Gig-LAN module, Can bus or COM ect |
LED | 1*Power LED, 1*HDD LED, 3*CPU temp LED?Red is warning , Yellow is high, Green is normal? |
Control SW | 1*Power button?1*Remote SW, 1*AT/ATX SW, 1*Clear CMOS SW |
Power supply | DC 9-36V, 1*3-pin phoenix term, with short circuit, over voltage and over current protection |
TDP: TBD |
Watchdog timer | Watchdog timeout programmable via software 1 to 255 second |
OS | Windows 10 64 bit, SUSE, Ubuntu, Wind River, Linux |
Mechanical | SGCC chassis, Aluminum frame |
Color | Blue+white gray |
Mounting | Desk mounting with rubber Rails, opt Din-Rail mounting |
Dimension | (L*W*H)?250*154*61.9mm |
Net weight | 2.55kg |
Operating temperature | -20?65?, wide temp SSD, airflow |
Storage temperature | -40°C~85°C |
Storage humidity | 10~90%@40°C, Non-condensing |
Vibration | 5grms/5~500Hz/ random/in working(SSD); 1grms/5~500Hz/random/in working(HDD) |
Shock | 50g peak acceleration(11ms duration)(SSD); 20g peak acceleration(11ms duration)(HDD? |
EMC/Certification | CE/FCC Class B |
