InnoOSR 2.5” SATA SSD 3TO7

2.5" SSD

World's First SSD for System Recovery

Features

Supports hardware GPIO and software-based triggering
Includes firmware-level backup to ensure seamless compatibility and system reliability
Offers a convenient one-click recovery feature for quick and efficient restoration

BORN FOR SUPERIOR PERFORMANCE

Innodisk InnoOSR 2.5” SATA SSD 3TO7 offers high-capacity flash memory, supporting up to SATA III (6.0Gb/s) speeds. The InnoOSR family features single-device, firmware-level LBA OS and data backup, enabling effortless on-site recovery through GPIO triggering or application commands. With its intuitive design, full recovery is just a click away. InnoOSR – RECOVERY WITH A SINGLE CLICK

SPECIFICATIONS

Model Name	InnoOSR 2.5” SATA SSD 3TO7
Flash Type	3D TLC
Interface	SATA III 6.0 Gb/s
Form Factor	2.5" SSD
Capacity	32GB ~ 2TB
Sequential R / W (MB/sec, max.)	550 / 510
P/E Cycle	3,000
TBW (Max.)	2,400
Storage Temperature	-40°C ~ 85°C
Max. Power Consumption	2.5W
Max. Channels	4
External DRAM Buffer	N
Feature	S.M.A.R.T.
Series	InnoOSR
Dimension (W x L x H/mm)	69.85 x 100.0 x 9.5
Vibration	20G@[7 ~ 2000Hz]
Shock	1500G@0.5ms
MTBF	>3 million hours
Warranty	3 Years

ORDER INFORMATION

Operating Temperature	Standard Grade (0°C ~ 70°C)	Industrial Grade (-40°C ~ 85°C)
32GB	DUS25-32GDK1EC1SFXXG	DUS25-32GDK1EW1SFXXG
64GB	DUS25-64GDK1EC1DFXXG	DUS25-64GDK1EW1DFXXG
128GB	DUS25-A28DK1%C*&FXXG	DUS25-A28DK1%W*&FXXG
256GB	DUS25-B56DK1%C*QFXXG	DUS25-B56DK1%W*QFXXG
512GB	DUS25-C12DK1%C*QFXXG	DUS25-C12DK1%W*QFXXG
1TB	DUS25-01TDK1%C*QFXXG	DUS25-01TDK1%W*QFXXG
2TB	DUS25-02TDK1KCAQFXXG	DUS25-02TDK1KWAQFXXG

%. E : 64 layers 3D TLC / K : 112 layers 3D TLC
*. PCB version control
&. S : 1 channel / D : 2 channels / Q : 4 channels
XXG : 10G ~ 30G, 60G, or 90G
