DDR4 Wide Temp. SODIMM

DDR4

Non-ECC Unbuffered Memory

Features

  • Small outline dual in-line memory module
  • Fully tested and optimized for stability and performance
  • Uses original IC to meet strict industrial standards
  • Anti-sulfuration protection against harsh environments
  • JEDEC standard 1.2V (1.26V ~ 1.14V)
  • Operating Environment: -40°C ~ 95°C (Tc)
  • 30?” Gold Finger
  • RoHS Compliance, CE / FCC Certification

BORN FOR SUPERIOR PERFORMANCE

DDR4 Wide Temperature SODIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 95°C (Tc), and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s and 2666MT/s modules are also available.


SPECIFICATIONS

Model Name

DDR4 Wide Temperature SODIMM

DDR Generation

DDR4 Memory

DIMM Type

SODIMM

Speed

2133 MT/s, 2400 MT/s, 2666 MT/s, 3200 MT/s

Density

4GB, 8GB, 16GB, 32GB

Function

Non-ECC Unbuffered Memory

Pin Number

260pin

Bus Width

x64

Voltage

1.2V

PCB Height

1.18 Inches

Operating Temperature

-40°C ~ 95°C (Tc)

30?” Gold Finger

Y

Anti-Sulfuration

Y


ORDER INFORMATION

P/N

IC Config.

Rank

Temp.

Description

M4S0-2GSVZ5EM

256M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 2GB Wide Temperature SODIMM

M4S0-4GSV85EM

256M x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GSSN5EM

512M x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GSXZ5EM

512M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GMXZ5EM

512M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-8GSX85EM

512M x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GSSO5EM

512M x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GS1N5EM

1G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GM1N5EM

1G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GSYZ5EM

1G x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-AGSY85EM

1G x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGS1O5EM

1G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGM1O5EM

1G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGS2N5EM

2G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGM2N5EM

2G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-BGS2O5EM

2G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 32GB Wide Temperature SODIMM

M4S0-BGM2O5EM

2G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 32GB Wide Temperature SODIMM


For more information, please contact our support.
